FURITEK LIZARD PRO 30A/50A BRUSHED/BRUSHLESS ESC FOR AXIAL SCX24 WITH FOC TECHNOLOGY.
FURITEK LIZARD PRO 30A/50A BRUSHED/BRUSHLESS ESC FOR AXIAL SCX24 WITH FOC TECHNOLOGY.

FURITEK LIZARD PRO 30A/50A BRUSHED/BRUSHLESS ESC FOR AXIAL SCX24 WITH FOC TECHNOLOGY

$64.99
You will earn 64.99 points for buying this product
style="display:none" ETA: 06/30/2024

*** Furitek Esc is not compatible with HRZ00015 Board ***

Features:
- Support sensorless brushless DC and brushed DC motor (config via app, default is brushless).
- FOC (Field-oriented control) technology.
- Plug & Play designed for AXIAL SCX24 crawlers.
- 5V/ 6.5V 2.5A Built-in BEC (config via app).
- Support 2S-3S lipo battery - Mini size and lightweight.
- Super easy programming via App on both Android and IOS.
- Firmware update available (Bluetooth module required).
- Real-time telemetry up to 10Hz - Ability to run with stock TX/RX or any other TX/RX.



⚠️⚠️⚠️ WARNING ⚠️⚠️⚠️
3s only works best with 2204 1400kv motors and 050 Brushed Motor


Specifications:
- Support 2S-3S lipo battery
- BIG BEC: 5V or 6.5V 2.5A (Don’t need external BEC if use big Servo)
- Constant current: 30A
- Burst current: 50A
- Build-in Switch power
- Dimension (mm): 28(L)x 15.5(W)
- Weight: 3.7 gram

Note: Furitek ESC only support: Komodo 2204 1400kv, Micro Komodo 3450kv, Mini Komodo 2000kv. Don't run motors with high KV like 4100 on 3S


What's included in the package?
1. Lizard Pro Esc x 1pc
2. Power Cable x 1pc
3. Heat Shrinkable Tube x 1 pc
4. Servo to Jst Receiver x 1 pc



Color: Blue, Purple, White
Size: 20, 24
Material: 100% Polyester

Customer Reviews

Based on 27 reviews
93%
(25)
4%
(1)
0%
(0)
4%
(1)
0%
(0)
L
Luke
Will not connect to bluetooth

I’ve spent hours reading and trying everything to. Object to the app with the success. Without being able to set up the ESC parameters properly this ESC is nothing different than anything else.

J
Jason Doppelt

FURITEK LIZARD PRO 30A/50A BRUSHED/BRUSHLESS ESC FOR AXIAL SCX24 WITH FOC TECHNOLOGY

E
Ed duChemin
Lizard

Definitely my go to esc. So smooth!

S
Steven mcgregor
If it's Furitek, it's quality

This is for those who might already have the blue tooth module or those who don't deem it necessary.
Regardless it's a Furitek product and it's FIRE!!!!

O
Old Man
Lizard Pro 👍👍

Love It … Easy to tune, very smooth operation….

m
michael b.(.
Furitek lizard pro esc

This thing is awesome showed up on time and works good

J
Jeez
Great, space-saving esc

Perfect for those cage builds with no space. Handles 3s brushless with ease. Doesn't come with the bluetooth adaptor to program. You can use a single bluetooth adaptor across multiple esc's however.

K
Kenny Miller

Very happy with all my furitek systems. I am a life time user ..

R
Ryan Burlow
Fantastic ESC!!!

Had some issues with my lizard ultimate esc and Tony Furitek replaced it with a pro!!! I figured I was just out of luck with it, but he came through!!! Thank you

M
Mike Landis
Lizard Pro

This is my second Lizard Pro. It is a great product. Simple installations with the Fly Sky GT-5. Easily programable. Great setup for my Class 2 Jeep
